4. Applications.

Least-squares problems arise in a number of ways. The simplest one is this:

Application 1. ``Linear regression''. Find the best-fitting straight line $y = c _ 0 + c _ 1 x$ for data points $(1,3), (2,3), (-2,-1), (-1,1), (2,2)$ (Figure ).

Figure: A linear fit

book/12dir/linear.eps

Solution. Here we need to find $c _ 0$ and $c _ 1$, not $x$ and $y$. If a data point $(2,5)$ (say) were to be on the line that would mean $5 = c _ 0 + c _ 1 2$. But there are too many data points to hope that they would all be on one line. Thus we have to settle for finding $c _ 0$ and $c _ 1$ so that

$$\begin{array}{ccc} c _ 0 + 1 c _ 1 &\approx &3 \\ c _ 0 + 2... ... c _ 1 &\approx &1 \\ c _ 0 + 2 c _ 1 &\approx &2 \end{array}$$

or in other words, $\left[\begin{array}{rr} 1&1\\ 1&2\\ 1&-2\\ 1&-1\\ 1&2 \end{array}\right] \... ...right] \approx \left[\begin{array}{c} 3\\ 3\\ -1\\ 1\\ 2 \end{array}\right]$, so the normal equations are

$\left[\begin{array}{rrrrr}1&1&1&1&1\\ 1&2&-2&-1&2\end{array}\right] \left[\be... ...array}\right] \left[\begin{array}{c} 3\\ 3\\ -1\\ 1\\ 2 \end{array}\right]$, or

$\left[\begin{array}{rr} 5&2\\ 2&14 \end{array}\right] = \left[\begin{array}{c} 8\\ 14 \end{array}\right]$. A computer solution gives $c _ 0 = 1.27273$, $c _ 1 = 0.81818$, to five decimal places. Thus the best-fitting straight line in the least-squares sense is $y = 1.27273 + 0.81818 x$.

In general, for data points $(r _ 1, s _ 1),\dots, (r _ m, s _ m)$ you get the normal equations

$\left[\begin{array}{cc} m& \sum _ i r _ i\\ \sum _ i r _ i&\sum _ i r _ i ^ 2... ...left[\begin{array}{c} \sum _ i s _ i\\ \sum _ i r _ i s _ i\end{array}\right]$.

It is all right to have some of the $r _ i$ be the same. These normal equations are guaranteed to be nonsingular as long as not all the $r _ i$ are the same. (If they were all the same, the data points would lie on a vertical line and there would be no one best-fitting linear function.)

Application 2. Finding a best-fitting quadratic. Given data points $(r _ 1, s _ 1)$, $\dots$, $(r _ m, s _ m)$, find the parabola $y = c _ 0 + c _ 1 x + c _ 2 x ^ 2$ that fits them best (Figure ). In other words, solve

$$\begin{array}{ccc} c _ 0 + c _ 1 r _ 1 + c _ 2 r _ 1 ^ 2 & \a... ...0 + c _ 1 r _ m + c _ 2 r _ m ^ 2 & \approx & s _ m \end{array}$$

Figure: A quadratic fit

book/12dir/quadratic.eps

At first this might not look like a linear problem. Notice, though, that the $r _ i$ and $s _ i$ are data numbers, and their powers are also just certain numbers. The unknowns are $c _ 0, c _ 1, c _ 2$, which appear linearly. In fact, a polynomial is a linear combination--of powers. In matrix form, this problem is

$\left[\begin{array}{ccc} 1& r _ 1& r _ 1 ^ 2\\ 1& r _ 2& r _ 2 ^ 2\\ \dots &... ...t] = \left[\begin{array}{c} s _ 1\\ s _ 2\\ \dots \\ s _ m\end{array}\right]$, or for short, $A$   c$\approx$   s.

Solving the normal equations gives us the best $c _ 0, c _ 1, c _ 2$.

Note. Although one can talk loosely of a ``best-fitting parabola'', if $c _ 2$ happened to come out to be zero the curve would actually be a straight line.

Application 3. Finding a best-fitting linear combination of polynomials of given degree $d$.

This is an obvious generalization of the quadratic case. For polynomials of degree $d$, the only requirement to guarantee nonsingularity of the normal equations is that $r _ 1,\dots, r _ m$ should include at least $d+1$ different numbers.

Application 4. Finding a best-fitting linear combination of functions. Given data points and a specified finite family of functions, find the linear combination of those functions that fits the data best.

In other words, suppose we are given functions $f _ 1,\dots f _ n$ and data points $(r _ 1, s _ 1),\dots, (r _ m, s _ m)$. We want to find coefficients $c _ 1,\dots, c _ n$ so that

$$\begin{array}{ccc} c _ 1 f _ 1 (r _ 1) + \dots + c _ n f _ n... ... m) + \dots + c _ n f _ n (r _ m)&\approx&s _ m\\ \end{array}$$.

This is just a least-squares problem $A$   c$\approx$   b, where $A = [f _ i (r _ j)]$ and b$= [s _ i]$. We'll discuss the particular case where the $f _ i$ are Chebyshev polynomials.

Application 5. Finding a best-fitting polynomial parametric curve near given data points.

Let's consider a cubic curve in two dimensions. We have times $t _ 0,\dots, t _ n$ and data points $P _ 1,\dots, P _ n$, and we want a cubic curve $P(t)$ so that $P(t _ i)$ is close to $P _ i$ for each $i$. As a measure of closeness we can use the Euclidean distance. In other words, we want to minimize the sum of squares of the errors dist$(P(t _ i), P _ i)$. This situation at first sounds different from the errors previously discussed, which were vertical distances on graphs, but see what happens: Write $P(t) = \left[\begin{array}{c}x(t)\\ y(t)\end{array}\right]$, $P _ i = \left[\begin{array}{c}x _ i\\ y _ i\end{array}\right]$. Then dist$(P(t _ i), P _ i)$ $=$ $\sqrt {(x(t _ i) - x _ i) ^ 2 + (y(t _ i) - y _ i) ^ 2}$, and the sum-of-squares error is the sum of squares of square roots: $E = \sum _ i (x(t _ i) - x _ i) ^ 2 + (y(t _ i) - y _ i) ^ 2$. So if we write $x(t) = c _ 0 + c _ 1 t + c _ 2 t ^ 2 + c _ 3 t ^ 3$ and $y(t) = d _ 0 + d _ 1 t + d _ 2 t ^ 2 + d _ 3 t ^ 3$, with coefficients to be determined, the sum-of-squares error is exactly the same as for the least-squares problem

$$\begin{array}{ccc} c _ 0 + c _ 1 t _ 1 + c _ 2 t _ 1 ^ 2 + c ... ...2 t _ n ^ 2 + d _ 3 t _ n ^ 3 & \approx & y _ n\\ \end{array}$$

Although squared errors from both $x$- and $y$-coordinates are added together, the errors involve separate sets of variables, so this problem is really equivalent to two separate least-squares problems $A$   c$\approx$   x and $A$   d$\approx$   y, where

$A = \left[\begin{array}{cccc} 1& t _ 1& t _ 1 ^ 2& t _ 1 ^ 3\\ 1& t _ 2& t _... ...s }&{\dots }&{\dots }\\ 1& t _ n& t _ n ^ 2& t _ n ^ 3\\ \end{array}\right]$,

c$= \left[\begin{array}{c}c _ 0\\ c _ 1\\ c _ 2\\ c _ 3\end{array}\right]$, d$= \left[\begin{array}{c}d _ 0\\ d _ 1\\ d _ 2\\ d _ 3\end{array}\right]$, x$= \left[\begin{array}{c}x _ 1\\ x _ 2\\ \dots \\ x _ n\end{array}\right]$, y$= \left[\begin{array}{c}y _ 1\\ y _ 2\\ \dots \\ x _ n\end{array}\right]$.

Since both problems share the same $A$, we can solve them together with normal equations

$A ^ t A C = A ^ t P$, where $C = \left[\begin{array}{cc}c _ 0& d _ 0\\ c _ 1& d _ 1\\ c _ 2& d _ 2\\ c _ 3& d _ 3\end{array}\right]$ and

$P = \left[\begin{array}{cc}x _ 1& y _ 1\\ x _ 2& y _ 2\\ {\dots }&{\dots }\\ x _ n& y _ n\end{array}\right]$ = the matrix of data points as row vectors.

Other applications. Large overdetermined arrays arise in many engineering design applications. The method of normal equations works well well even if $A$ is $1000 \times 50$. (On modern workstations it takes less than a second to solve a $50 \times 50$ set of linear equations.)
